DONNÉES D’ENTRÉE
- Smart LCD setting (Working modes, Charge Current, Charge voltage, etc.)
- Built-in MPPT solar charge controller 80A/100A/200A
- MPPT efficiency max 98%
- Powerful charge rate up to 140Amp
- DC start & Automatic Self-Diagnostic Function
- WI-FI / USB monitoring function (wi-昀椀 optional)
- Supporting AGS, BTS port
- Compatible to generator
INVERTER OUTPUT
- Rated power 12.0KW
- Surge rating 36000VA
- Capable of starting electric motor 6HP
- Waveform : Pure sine wave \ same as input (bypass mode)
- Nominal output voltage RMS 220V \ 230V \ 240VAC (±10%RMS)
- Output frequency: 50Hz \ 60Hz ± 0.3Hz
- Inverter efficiency (peak): >85% >88%
- Line mode efficiency : >95%
- Power factor: 1.0
- Typical transfer time : 20ms (max)
AC INPUT :
- Voltage: 230VAC
- Selectable voltage range: 90-280 VAC (APL)
- Frequency range: 50Hz \ 60Hz
OTHER
- Operation temperature range: 0°C to 40°C
- Storage temperature: -15°C to 60°C
- Audible noise: 60dB MAX
- Display: LED+LCD
- Loading (20GP/40GP/40HQ): 140pcs \ 280pcs \ 320pcs
